CMS6025-LED 1156 / 1157 / S25 SMD 9

🔹 Product Overview

The CMS6025-LED 1156/1157/S25 SMD 9 is a high-performance automotive LED bulb engineered for durability, thermal efficiency, and wide voltage compatibility. Designed for professional automotive and commercial vehicle applications, this model has been widely recognized and approved by customers.

1️⃣ Glass Bulb Housing – UV Resistant

• Uses a premium glass bulb shell
• UV-resistant and anti-yellowing
• Maintains optical clarity over long-term exposure to sunlight
• Protects LEDs from external impact and environmental sulfide corrosion
• Enhances thermal stability

2️⃣ Advanced Thermal Management Design

• Special heat dissipation structure
• Flexible PCB with thermal compression bonding
• Tightly integrated with pure aluminum metal base
• Efficient heat transfer and improved luminous efficiency
• Ensures stable long-term performance

3️⃣ Wide Voltage Design (10–30V DC)

• Supports 10–30VDC input
• Suitable for both 12V and 24V vehicle systems
• Stable and reliable output across passenger cars, trucks, trailers, and heavy-duty vehicles

4️⃣ High Power & Efficiency

• 9 high-power SMD LEDs
• Power consumption: approx. 3.4W
• High luminous efficiency with enhanced brightness
• Energy-saving while maintaining superior visibility

5️⃣ Multiple Vehicle Applications

Designed for:

• Turn Signal Lights
• Brake Lights
• Running Lights
• Daytime Running Lights (DRL)
• Reverse Lights
• Side Marker Lights
• Trailer Lights
• Emergency & Warning Applications

6️⃣ Easy Installation

• Base Type: 1156 / 1157 / S25
• Direct replacement design
• Please confirm bulb base compatibility before installation

7️⃣ Stable & Durable Performance

• Low power consumption with higher luminous output than traditional bulbs
• Robust construction for vibration resistance
• Proven reliability and customer approval

8️⃣ Important Installation Note

When used as a turn signal replacement, a load resistor or compatible flasher relay may be required to prevent hyper flashing.
