LED CMBAX1711-EBSR Dashboard Lights

Applications

Dashboard lights – The LED CMBAX1711-EBSR Dashboard Light provides clear illumination for vehicle dashboards, ensuring indicators are easily visible to drivers.

Instrument cluster lights – The LED CMBAX1711-EBSR improves visibility of instrument panels, helping drivers read dashboard information more clearly.

Gauge backlighting – Ideal for illuminating vehicle gauges to enhance readability in low-light driving conditions.

Indicator lights – Suitable for use as dashboard indicator lamps such as turn signal indicators, high beam indicators, warning lights, and other instrument panel signals.

Product Overview

The LED CMBAX1711-EBSR Dashboard Light is designed with a high-efficiency LED chip that provides a wide illumination angle of 120°, ensuring uniform light distribution across vehicle instrument panels.

With a brightness output of up to 16 lumens, the LED provides clear and visible indicator lighting on dashboards, helping drivers quickly recognize vehicle status signals and improving driving safety.

Compared with traditional incandescent bulbs, the LED CMBAX1711-EBSR offers significantly improved brightness, lower power consumption, and longer service life.

The bulb operates on 12V DC or 24V DC, making it suitable for passenger cars, trucks, buses, motorcycles, and other vehicles.

To ensure reliable electrical performance in automotive environments, the LED uses high-strength metal contact spring terminals, providing stable electrical contact and preventing poor connections caused by vehicle vibration.

With continuous product development and manufacturing experience, Chi Ming Electronics Corp. has optimized the reliability and durability of dashboard indicator lighting. The LED CMBAX1711-EBSR is part of our core instrument lighting product line and is widely used in both OEM and aftermarket vehicle applications.

Available Colors

White
Red
Yellow
Blue
Green

These color options allow dashboard indicators to match different vehicle functions and improve both visibility and aesthetic customization.

Suitable for:

• Passenger cars

• Trucks

• SUVs

• Vans

• Motorcycles

• Commercial vehicles

Product Series Availability

In addition to the LED CMBAX1711-EBSR, Chi Ming Electronics Corp. provides a complete range of dashboard indicator LED bulbs, including:

• B8.3D

• B8.4D

• B8.5D

• B8.7D

• BAX

• EBSR

and other instrument cluster base types.

This comprehensive product portfolio allows Chi Ming Electronics Corp. to support both OEM and aftermarket customers with a wide variety of dashboard lighting solutions for different vehicle models and instrument cluster designs.

Key Features

• Wide 120° illumination angle for improved dashboard visibility
• Brightness up to 16 lumens for clear indicator lighting
• High-efficiency LED technology
• 12V DC / 24V DC wide voltage compatibility
• High-strength metal contact spring terminals for reliable electrical connection
• Resistant to vibration and suitable for automotive environments
• Long service life up to 30,000 hours
• Low power consumption and energy-efficient design
• Complete dashboard LED series for multiple base types

Important Note

Please confirm the bulb model, base type, and dimensions before installation to ensure proper compatibility with the vehicle instrument panel.
