CM1545-Flange Base Dashboard LED 1
CM1545 – Flange Base Dashboard LED 1
Applications
The CM1545 – Flange Base Dashboard LED 1 is designed for a wide range of automotive, truck, and motorcycle dashboard lighting applications, including:
Instrument Cluster & Gauge Lights
Provides clear illumination for vehicle dashboards and instrument meters.
Backlight & Clock Lights
Suitable for dashboard backlighting and clock illumination.
Ash Tray & Radio Dial Lights
Enhances visibility for interior control panels and dashboard components.
Ignition & Warning Indicators
Ideal for check engine, battery, transmission, and warning signals.
Turn Signal & High Beam Indicators
Ensures clear signal indication for safer driving.
Parking Brake & Seatbelt Indicators
Provides reliable illumination for essential safety indicators.
Product Features
Wide-Angle Flat-Top LED Design
The LED adopts a flat-top structure, providing a wide 90° illumination angle for more uniform light distribution across dashboard panels.
Dual Voltage Compatibility
Available in 12V DC and 24V DC versions, suitable for passenger vehicles, trucks, motorcycles, and commercial vehicles.
Energy Efficient
Low power consumption of approximately 0.27W, providing bright illumination with minimal energy usage.
Pure Copper Flange Base
The Flange base is manufactured from pure red copper, ensuring excellent electrical conductivity and improved heat dissipation, resulting in higher stability and longer service life.
Durable LED Structure
The LED chip is securely fixed with PC plastic housing, providing strong vibration resistance and stable performance under vehicle operating conditions.
Proven Market Performance
This model has been marketed for many years and remains one of our best-selling products, offering excellent price-to-performance value for OEM and aftermarket customers.
Key Specifications
| Item | Specification |
|---|---|
| Model | CM1545 |
| Base Type | Flange Base |
| LED Type | Flat-top LED |
| Beam Angle | 90° |
| Voltage | 12V DC / 24V DC |
| Power | approx. 0.27W |
| Structure | Pure Copper Base + PC LED Holder |
| Applications | Dashboard / Indicator Lights |
| Lifespan | Long-life LED |
Note
Please confirm the model number, base type, dimensions, and voltage specifications (12V / 24V DC) before installation.
For 24V truck applications, OEM customization, or ODM projects, please contact us for technical support and compatibility confirmation.
