CMS6006 – LED COB Soft Strip Lights
📄 Product Overview
The CMS6006 – LED COB Soft Strip Lights are engineered for professional automotive, commercial vehicle, and ambient lighting applications.
Featuring advanced High Brightness COB (Chip On Board) technology and a premium flip-chip reflow soldering process, the CMS6006 delivers superior heat resistance, stable performance, and outstanding long-term durability.
Designed with a double-layer copper PCB structure, the strip ensures excellent current transmission and efficient heat dissipation, allowing stable and consistent light output even under demanding environments.
The white light version provides brightness up to 680LM, offering excellent illumination performance with outstanding cost efficiency.
The CMS6006 operates on 12VDC or 24VDC low-voltage systems, making it safe, energy-efficient, and suitable for a wide range of vehicle applications.
The rear side is equipped with a strong 3M adhesive backing, enabling quick and easy installation on clean and smooth surfaces.
Its IP67 waterproof construction ensures reliable operation in outdoor, underbody, and rugged environments.
The CMS6006 is available in multiple lighting colors including:
- White
- Warm White
- Amber
- Red
- Blue
- Green
- Ice Blue
- Lemon Yellow
With a smooth 180° wide beam angle, the CMS6006 produces uniform, dot-free illumination for premium ambient and contour lighting effects.
In addition, the strip is highly flexible and easy to customize.
It can be cut every 50mm, allowing users to DIY customized lengths according to project requirements.
Each meter of CMS6006 contains approximately 420 LED chips, delivering dense, continuous, and uniform lighting performance.
Trusted by customers worldwide for brightness, stability, and long-term reliability.
📐 Specifications
| Item | Specification |
|---|---|
| Model | CMS6006 – LED COB Soft Strip Lights |
| Input Voltage | 12VDC / 24VDC |
| LED Type | COB LED |
| LED Density | 420 LEDs / Meter |
| Beam Angle | 180° Wide Beam |
| Waterproof Rating | IP67 |
| PCB Structure | Double-Layer Copper PCB |
| Mounting | 3M Adhesive Backing |
| Cutting Unit | Every 50mm |
| Available Colors | White / Warm White / Amber / Red / Blue / Green / Ice Blue / Lemon Yellow |
| White Light Brightness | Up to 680LM |
| Lifespan | Over 50,000 Hours |
🔧 Applications
The CMS6006 is widely used in various vehicle and decorative lighting applications, including:
- Vehicle Interior Cabin Lighting
- Truck & RV Ambient Lighting
- Vehicle Contour / Outline Lighting
- Underbody Ground Effect Lighting
- Door Outline Lighting
- Footwell Lighting
- Side Marker & Decorative Lighting
- Commercial Vehicle Interior Lighting
- Auxiliary Safety Lighting
Its slim and flexible structure makes it ideal for hidden, curved, and narrow installation spaces.
💡 Key Features
✔ High Brightness COB LED Technology
✔ Advanced Flip-Chip Reflow Soldering Process
✔ Excellent Heat Dissipation Performance
✔ Stable & Uniform Light Output
✔ 180° Wide Beam Angle
✔ Double-Layer Copper PCB Structure
✔ IP67 Waterproof & Dustproof
✔ Strong 3M Adhesive Backing
✔ Flexible & Easy Installation
✔ Cuttable Every 50mm for DIY Customization
✔ Excellent Shock & Vibration Resistance
✔ High Temperature Resistance
✔ Long Lifespan Over 50,000 Hours
✔ Suitable for OEM / ODM Custom Projects
📌 Installation Notes
- Clean and dry the mounting surface before installation.
- Use alcohol to remove dust, oil, or moisture for maximum adhesion performance.
- Press firmly along the entire strip after installation.
- Avoid excessive bending at sharp angles.
- Ensure correct voltage selection (12VDC or 24VDC) before connection.
🚛 Engineered for Professional Vehicle Lighting
The CMS6006 LED COB Soft Strip Lights are designed to deliver:
High Brightness • Uniform Illumination • Stable Performance • Long-Term Reliability
Ideal for:
- Trucks
- RVs
- Pickup Trucks
- Commercial Vehicles
- Interior Ambient Lighting
- Exterior Contour Lighting
- OEM Vehicle Lighting Projects
