🔧 CMF1042-LED SV8.5 Festoon Bulb HP 2

OEM Engineering Description（Commercial Vehicle Grade）

1️⃣ Reinforced Dual-Layer Copper Contact Structure 🔩

The CMF1042-LED SV8.5 is engineered with a dual-layer pure copper SV8.5 cap design, delivering:

• Superior mechanical fixation
• Excellent vibration resistance
• Stable and low-resistance electrical conductivity

👉 A unique structural advantage for heavy-duty and fleet applications

2️⃣ Advanced Thermal Path Design 🔥

Optimized for long-term stability with enhanced heat dissipation:

• PCB bottom tightly bonded to copper pillars using high-temperature soldering
• Direct thermal conduction path from LED chip to metal base
• Reduced thermal accumulation during continuous operation

👉 Ensures stable luminous output and extended product lifespan

3️⃣ Wide Voltage Compatibility ⚡

Designed for 10–30V DC wide voltage systems, supporting:

• 12V passenger vehicles
• 24V trucks and buses
• Commercial & industrial vehicles

👉 Reliable performance across diverse vehicle electrical platforms

4️⃣ High Reliability in Harsh Environments 🛡️

Built to withstand demanding operating conditions:

• Anti-vibration structural design
• Stable output under continuous use
• Durable for long-term operation

👉 Ideal for fleet, logistics, and heavy-duty vehicle applications

5️⃣ Energy Efficient & Stable Output 💡

• Light Source: High-efficiency LED (XPE ×2)
• Luminous Flux: Up to 100LM
• Low power consumption design

👉 Delivers consistent brightness with optimized energy efficiency

6️⃣ Wide Application Range 🚗

Suitable for multiple automotive lighting applications:

• Dome lights
• Reading lights
• License plate lights
• Cabin / trunk lighting
• Courtesy lights

👉 Fully compatible with SV8.5 festoon socket systems

7️⃣ Flexible Dimensions & Easy Installation 📏

• Base: SV8.5 Festoon
• Multiple length options available (customizable)
• Plug-and-play installation

👉 Direct replacement for traditional incandescent festoon bulbs
