🔷 LED CMF1039-LED SV8.5 FESTOON SMD 3

🔹 Product Description（優化完成版）

Wide Beam & Soft Illumination

Designed with a 120° wide beam angle, the CMF1039-LED SV8.5 FESTOON SMD 3 delivers up to 40 lumens, providing smooth, uniform, and glare-free illumination—ideal for interior lighting applications.

Efficient & Reliable Performance

With ultra-low power consumption of only 0.9W, this LED ensures stable brightness with minimal heat generation.
Fully compatible with 12VDC and 24VDC systems, making it suitable for passenger and commercial vehicles.

Premium Structural Design（🔥差異化重點）

This model features a high-transparency PC lens, offering excellent light transmission and consistent illumination quality.

In addition, it is equipped with a pure copper sleeve structure, which provides:

• Enhanced mechanical strength

• Improved heat dissipation efficiency

• Stable luminous output over long operation

• Excellent vibration resistance for harsh environments

👉 This unique structural design reflects Chi Ming’s commitment to durability, stability, and long-term quality performance.

Versatile Applications

Perfect for various vehicle interior and auxiliary lighting applications:

• Vanity mirror lights

• Reading lights

• License plate lights

• Dome & map lights

• Door courtesy lights

Fully compatible with SV8.5 festoon base sockets.

Flexible Sizing Options

• Width: 10mm

• Length options: 31mm / 36mm / 39mm / 42mm
  (Custom sizes available upon request)

Color Options

• 6000K Cool White (Standard)

• 2700K Warm White

• Custom colors: Red, Amber, Green, Blue, etc.

Easy Installation

• Direct plug-and-play replacement

• No rewiring required

Note

Please verify bulb size and base type before installation.
For OEM / ODM projects or customized specifications, feel free to contact us.
