CMWL57130 – LED Warning Light

Product Overview

The CMWL57130 LED Warning Light is designed for commercial, construction, and industrial vehicles requiring reliable visual warning performance. Featuring a wide voltage system and heavy-duty magnetic base, it ensures stable operation even in harsh working environments.

Key Features

■ Wide Voltage Design

Operates on 10–30VDC, compatible with 12V and 24V vehicle systems.
Built-in PWM module ensures stable current control, reduced power loss, and efficient heat dissipation.

■ Dual Warning Modes

• Rotating mode
• Flashing (strobe) mode

Strobe frequency: 46 flashes/min
Rotation frequency: 118 rpm

■ High-Efficiency LED System

Equipped with 36 pcs SMD3030 LEDs (PC-Amber)
Delivers high visibility and reliable warning performance.

■ Super Strong Magnetic Base

Heavy-duty magnetic design firmly attaches to metal surfaces.
Maintains strong adhesion even under vibration, wind, and rain.
Easy installation — no drilling required.

■ Anti-Vibration Structure

Reinforced housing and internal structure designed for:
• Construction vehicles
• Crane trucks
• Bulldozers
• Road maintenance vehicles
• Industrial equipment

■ Waterproof Protection

IP65 rated housing for reliable outdoor operation.

■ Plug & Control

Cigarette lighter plug with:
• Power switch
• Rotation / Flash mode switch

Simple plug-and-play installation.

■ Custom Color Options

Available upon request:
Amber (standard), Red, Blue, Green, Warm White, and other custom colors.
