LED CMW2913 – T13 Wedge LED 6

1. High Brightness & Reliable Performance

The CMW2913-T13 Wedge LED 6 is equipped with 6 high-efficiency LEDs, delivering stable illumination with up to 45 lumens output.
This product has proven reliability and is widely recognized by customers for consistent performance and durability.

2. Focused Light Design

The LEDs are designed with a narrow beam angle, providing a focused lighting effect.
This concentrated light distribution makes the lamp particularly suitable for interior lighting, reading lights, and various indicator or signal applications.

3. Enhanced Thermal Management

A 3 mm spacing between the LED chips and the PCB improves heat dissipation.
This design allows the LED to maintain stable luminous output and longer operational life, even during extended operation.

4. Energy Efficient Operation

Power consumption is only 0.45W, providing excellent energy efficiency while maintaining sufficient brightness for automotive lighting applications.

5. Voltage Compatibility

Available in:

• 12V DC

• 24V DC

Suitable for use in:

• Passenger vehicles

• Trucks

• Motorcycles

• Utility vehicles

• Commercial vehicles

6. Applications

The CMW2913 T13 Wedge LED 6 is ideal for:

• Interior cabin lighting

• Reading lights

• License plate lights

• Side marker lights

• Dashboard indicators

• Signal and warning lights

• Trunk illumination

7. Color Options

Standard color temperature:

• 6000K Cool White

Custom colors available:

• Red

• Amber

• Blue

• Green

• Other customized colors upon request

8. Durable & Vibration-Resistant Structure

The lamp housing is made from high-quality polycarbonate (PC), offering excellent transparency and strong mechanical stability.

Material Specifications

• Material: Polycarbonate (PC)

• High Temperature Resistance: Up to 80°C

• Vibration Resistance: Excellent stability under vehicle vibration conditions

• Optical Performance: High light transmission and durable structure

The PC lens structure firmly secures the LEDs, ensuring stable lighting performance and improved durability for automotive environments.
