CM3618-T18 BA15S LED 5
CM3618-T18 BA15S LED 5
Product Description & Applications
-
Vehicle & Equipment LED Applications
The CM3618-T18 BA15S LED 5 is designed for automotive and truck lighting applications, including vehicle rear lights, position lights, reading lights, and side lights.
It is suitable for car LED and truck LED systems, offering stable illumination and long service life. -
BA15S Base – Non-Polar Design
Equipped with a BA15S single-contact base, the CM3618-T18 BA15S LED 5 features a non-polar design, allowing installation without concern for polarity.
Compatible with 12V / 24V / 48V DC and AC systems, ensuring flexible and easy installation across various applications. -
Wide Application Range
Suitable for use in:-
Direction lights
-
Reversing lights
-
Tail lights
-
Brake lights
-
Corner lights
-
Side marker lights
-
Parking lights
-
Emergency and warning lights
-
Industrial machinery warning lights
-
Marine and ship warning lights
-
-
Bulb Size Confirmation Required
Please check your vehicle owner’s manual or the original bulb specification to confirm the correct bulb size and base type before ordering. -
Voltage Awareness
Ensure the power supply voltage matches the designed voltage rating of the LED bulb before use. -
Long Life & Energy Efficiency
-
Lifespan: Up to 50,000 hours
-
Power Consumption: 0.45W
-
Equivalent Output: Approx. 5W incandescent lamp
The CM3618-T18 BA15S LED 5 is stable, shock-resistant, and designed to achieve energy-saving and environmentally friendly performance.
-
Note 1
Please carefully check the model and size before purchasing.
If you need assistance with compatibility or application selection, feel free to contact us.
Note 2
Please pay close attention to the power supply voltage before use.
If the applied voltage exceeds the designed voltage rating of the LED bulb, the bulb may be damaged or burned out.
The voltage rating is clearly marked on the LED bulb base—please ensure the correct operating voltage is used during installation.
